Name: Hitachi excavator HMGF033CA Travel motor assembly replacement EX200-2 9101523
Brand: GUANGZHOU BELPARTS ENGINEERING MACHINERY LIMITED
SKU: Ex200-2
Price: 475.00 USD
Availability: InStock

خونه > محصولات > راهنمای موتور سفر >

Hitachi excavator HMGF033CA Travel motor assembly replacement EX200-2 9101523

Hitachi excavator travel motor assembly,EX200-2 travel motor replacement,Hitachi HMGF033CA motor assembly

EX200-2 travel motor replacement

Hitachi HMGF033CA motor assembly

محل منبع:

ساخته شده در چین

نام تجاری:

Belparts

شماره مدل:

Ex200-2

با ما تماس بگیرید

درخواست نقل قول

Hitachi excavator HMGF033CA Travel motor assembly replacement EX200-2 9101523

جزئیات محصول

مدل:

Ex200-2

شماره قطعه:

9101523

نام بخشی:

جعبه گیربکس نهایی

نور افکنی:

بیل مکانیکی HMGF033CA EX200-2 9101523 موتور مسافرتی هیدرولیک

کاربرد:

قطعات یدکی بیل مکانیکی

نام بخشی:

موتور سفر حفاری

وضعیت:

OEM/ اصیل/ استفاده شده

تحویل:

3-7 روز

شرایط پرداخت و حمل و نقل

مقدار حداقل تعداد سفارش

1 عدد

قیمت

Negotiated price

جزئیات بسته بندی

مورد چوبی

زمان تحویل

1 ~ 3 روز

شرایط پرداخت

T/T ، تضمین تجارت ، پی پال

قابلیت ارائه

1000 قطعه قطعه

محصولات مرتبط

Hitachi ZX330-3 final drive assy 9190296 9195488 excavator hydraulic motor

بهترین قیمت رو بدست بیار

Hitachi excavator HMGF033CA Travel motor assembly replacement EX200-2 9101523

بهترین قیمت رو بدست بیار

Belparts excavator HMGF033CA EX200-2 9101523 hydraulic travel motor assy kit

بهترین قیمت رو بدست بیار

Belparts excavator R330LC-9S 31Q9-40011 travel motor gearbox for hyundai parts

بهترین قیمت رو بدست بیار

با ما تماس بگیرید

+86 13247509480

belparts02@gmail.com

86-020-32384870

حالا تماس بگیرید

توضیحات محصول

Hitachi excavator HMGF033CA Travel motor assembly replacement EX200-2 9101523

Product Specifications

Model	HMGF033CA EX200-2
Part Name	Excavator Travel Motor
Part Number	9101523 2026713
Place of Origin	China/ Other Country
Condition	OEM/ Genuine/Used
Warranty	12 months
Standard or Nonstandard	Standard
Payment Term	L/C, T/T, Trade Assurance
Delivery Time	1-3 days (depend on order)
Means of Transport	By Sea, Air or DHL
Guarantee	We will check and send detailed pictures to buyers for confirmation

List of spare parts

#	Part No	Part Name	Qty.
	9101523	MOTOR; OIL	1
01	1014547	. HOUSING	1
04	2026713	. DISC; DRIVING	1
06	4198783	. BRG; ROL	1
07	4198998	. BRG.; ROL.	1
08	4222980	. SPACER	1
09	4178173	. NUT; BRG.	1
11	4260561	. SEAL; OIL	1
12	4116290	. RING; RETAINING	1
14	2032256	. ROTOR	1
17	8050658	. PISTON	7
19	4262045	. SHAFT; CENTER	1
20	4246613	. SPRING; COMPRES.	1
21	4198956	. PIN	1
22	4234229	. RING; RETAINING	1
24	3037401	. PLATE; FRICTION	4
25	3032432	. PLATE	5
26	4246784	. SPACER	1
28	3047473	. PISTON	1
29	4232766	. D-RING	1
30	4232767	. D-RING	1
31	3047472	. SPRING; DISC	1
33	4248871	. O-RING	1
34	4506415	. O-RING	1
37	9101524	. VALVE; BRAKE	1
38	M341650	. BOLT; SOCKET	8
40	3050071	. PLATE	1
41	4266256	. PIN; KNOCK	2
45	1016649	. VALVE	1
46	4234628	. BUSHING	1
48	3052403	. LINK	1
49	4255238	. PLUG	2
51	4262561	. BOLT; REAMER	1
54	9101386	. PISTON; SERVO	1
55	4260308	. RING; PISTON	2
56	4275286	. COVER	1
57	4265579	. O-RING	1
58	M341225	. BOLT; SOCKET	4
60	9089487	. PLUG	1
60A	4506418	.. O-RING	1
62	9089484	. PLUG	2
62A	4506408	.. O-RING	1

The excavator travel motor is a hydraulic-driven component that converts hydraulic energy into mechanical rotation. High-pressure oil from the pump enters the motor, actuating pistons or gears to generate torque. A built-in reduction gear (often planetary) increases output force while reducing speed, driving the sprocket and tracks.

Key features include:

Bi-directional operation (forward/reverse via hydraulic flow control)
Integrated brakes for slope stability
Multi-speed control (some models)

Maintenance focuses on seal integrity, bearing wear, and hydraulic fluid cleanliness to prevent leaks and ensure efficiency. These motors provide high torque for rough terrain while enabling precise movement.
